FB-PC4002HF
YINYUAN New Materials
Semi-transparent granules
Polycarbonate
< 0.3
350
PC Films, PC Boards
| Quantity: | |
|---|---|
FB-PC4002HF
Non-halogenated Flame Retardant Masterbatch for Polycarbonate
Product Description:
FB-PC4002H is a non-halogenated flame retardant masterbatch, with polycarbonate (PC) as the carrier resin. It achieves its good flame retardancy by good compatibility with polymer resins, low blooming. FB-PC4002H flame retarded PC exhibits good mechanical and physical properties, good light transparency, and low side effect on yellowing resistance. This eco-friendly product is free of PFAS, suited for applications such as PC injection molding, PC films, etc.
Good thermal stability and less blooming.
Flame retarded materials exhibit good physical and mechanical properties.
Flame retarded material has fewer side effects on yellowing resistance property.
Non-halogenated flame retardant with favourable environment and health profile.
| Characteristics | Unit | Target Value |
| Appearance | Semi-transparent Granule | |
| Moisture/Water | % (w/w) | < 0.3 |
| Decomposition Temperature | ℃ | > 350 |
FB-PC4002HF is widely used in applications such as PC modification, injection molding, plastic calendering, etc. A dosage of approximate 5.0-10.0% of FB-PC4002HF is usually sufficient to obtain UL94 V-0 (1.6-3.2mm) flame retardant rating.
Formula and Physical Property Data:
| Characteristics | Test Method | Unit | Formula A | Formula B | Formula C |
| PC | % (w/w) | 100.0 | 95.0 | 90.0 | |
| FB-PC4002HF | % (w/w) | 5.0 | 10.0 | ||
| Tensile Strength | ASTM D638 | MPa | 70.2 | 67.1 | 64.9 |
| Elongation at Break | ASTM D638 | % | 130.3 | 90.5 | 76.2 |
| IZOD Impact Strength | ASTM D256 | kJ/m2 | 79.4 | 72.5 | 69.2 |
| Flame Retardant Rating | UL94 | V-2 (1.6mm) | V-1 (1.6mm) | V-0 (1.6mm) |
FB-PC4002HF may be affected by toughener and the recommended dosage should be no more than 1% (w/w).
FB-PC4002HF has synergistic effect with anti-dripping agents (e.g. FR-PT105).
Packing and Handling:
Delivery Form：
Semi-transparent granule.
Packing:
FB-PC4002HF is packed in paper-plastic bags with polyethylene inliner, 25kg per package.
Storage:
FB-PC4002HF should be stored in a dry and cool place, avoid direct sunlight.
