FR-NSB02 is white powder non-halogenated flame retardant, especially designed for antimony oxide (Sb2O3) replacement. It is particularly suitable for materilas such as PVC wire and cable, leather, canvas, etc. This product achieves excellent flame retardant effects by good thermal stability, and less side effects on mechanical and electrical properties of compounds.
FR-NSB02
Yinyuan
< 0.3
White powder
> 400
PVC
| Quantity: | |
|---|---|
FR-NSB02
Antimony Oxide Replacement Flame Retardant for PVC
Product Description：
FR-NSB02 is specially designed to antimony oxide (Sb2O3) replacement for polyvinyl chloride (PVC). This non-halogenated product offers a higher limiting oxygen index (LOI) value compared to conventional NSB solutions which exhibiting an lower LOI value for PVC materials. It is particularly suitable for materials such as PVC wires and cables, leather, canvas, etc. FR-NSB02 achieves excellent flame retardant effects through good thermal stability, high whiteness, and minimal side effects on the physical, mechanical, and electrical properties of the flame retarded materials.
Specifications：
Parameter | Unit | Target Value |
Appearance | white powder | |
Water/ Moisture | % (w/w) | < 0.3 |
Whiteness | > 95 | |
Decomposition Temperature | ℃ | > 400 |
Applications：
In soft PVC, a dosage of 1.1 to 1.2 times that of FR-NSB02 is usually sufficient to achieve equivalent effects of Sb2O3 LOI and flame retardant grade, as well as good its dispersibility and mechanical properties.
Application cases:
Formulation:
Characteristics | Unit | Sb2O3 | FR-NSB | FR-NSB02 |
PVC SG-3 | part | 100.0 | 100.0 | 100.0 |
DOTP | part | 50.0 | 50.0 | 50.0 |
CaCO3 | part | 22.0 | 22.0 | 22.0 |
Kaolinite | part | 8.0 | 8.0 | 8.0 |
CPE | part | 7.0 | 7.0 | 7.0 |
Stabiliser | part | 5.0 | 5.0 | 5.0 |
Al(OH)3 | part | 3.0 | 3.0 | 3.0 |
Zinc Borate | part | 6.0 | 6.0 | 6.0 |
Antimony Oxide | part | 4.0 | - | - |
FR-NSB | part | - | 4.8 | - |
FR-NSB02 | part | - | - | 4.8 |
Physical Property Data:
Characteristics | Unit | Sb2O3 | FR-NSB | FR-NSB02 |
Oxygen Index | % | 30.0 | 27.8 | 30.2 |
Tensile Strength | MPA | 17.4 | 15.2 | 17.7 |
Fracture Elongation | % | 337 | 274 | 335 |
Volume Resistivity | Ω * m | 1.389*1011 | 1.379*1011 | 1.718*1011 |
Congo Red Time | min | 92.2 | 91.4 | 92.3 |
Packing and Handling：
Delivery form:
White powder.
Packing:
FR-NSB02 is packed in paper-plastic bags, 25kg per package.
Storage:
FR-NSB02 must be sealed, stored in a dry and cool place.
