FR-NSB100
YINYUAN New Material
White Powder
PBT modified plastic
| Quantity: | |
|---|---|
FR-NSB100
Replacement of Antimony Oxide, Antimony-free Synergistic Flame Retardant for Polyester
Product Description：
FR-NSB100 is a white powder, which is designed for PBT as a substitute for antimony oxide (Sb2O3) synergistic flame retardant. Antimony-free, high-efficiency product offers an advantageously condensed phase mode to protect the polymers. It has good compatibility with resin, paving the way for minimising the brittleness of polyester compounds. Multiple color solutions would be implemented to enable broader applications of flame retarded materials.
Specifications：
Parameter | Unit | Target Value |
Appearance | white powder | |
Water/ Moisture | % (w/w) | < 0.2 |
Density | g/cm3 | 2.0-2.5 |
Average Particle Size (D50) | μm | 10-30 |
Applications：
FR-NSB100 is developed especially for use in polyester. It is particularly suited for both glass-fiber reinforced and non-reinforced PBT.
Formulation:
In 30% glass-fiber reinforced PBT, a dosage of about 5% of FR-NSB100 is usually sufficient to obtain the UL 94 V-0 classification, with tensile and impact strength comparable to conventional antimony synergistic flame retardant. Subject to the polymer grade, processing conditions and glass-fibre reinforcement, the dosage of FR-NSB100 may vary.
The flame retarded polyester compounds exhibit good physical and electrical properties in repeated secondary treatment. Non-halogenated flame retardant compliants with ROHS and REACH regulations.
Same colour as the antimony synergistic system, no colour-matching issues.
Application cases:
Characteristics | Unit | Sb2O3 | FR-NSB100 |
PBT/30GF | part | 87.5 | 84.5 |
Brominated Epoxy | part | 10.0 | 10.5 |
Synergist | part | 2.5 | 5.0 |
Melting Index | g/10min | 21 | 17 |
Density | g/cm3 | 1.66 | 1.62 |
Tensile Strength | MPA | 126 | 121 |
Fracture Elongation | % | 11.2 | 10.7 |
Bending Strength | MPa | 181 | 175 |
Impact Strength | kJ/m3 | 8.6 | 8.6 |
Note：PBT, 0.82 viscosity; fiberglass, JUSHI ER14-2000-988A.
Packing and Handling：
Delivery form:
White powder.
Packing:
FR-NSB100 is packed in paper-plastic bags, 25kg per package.
Storage:
FR-NSB100 must be sealed, stored in a dry and cool place.
